Gem5模拟器配置StreamPrefecher

发表于 阅读次数： 本文字数： 11k 阅读时长 ≈ 10 分钟

Gem5默认不支持StreamPrefetcher，为了在各级缓存使用StreamPrefetcher，需进行如下配置：

一、添加预取算法

文件路径：./src/mem/cache/prefetch/stream.cc

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197

#include "mem/cache/prefetch/stream.hh"

#include <cassert>

#include "base/intmath.hh"
#include "base/logging.hh"
#include "base/random.hh"
#include "base/trace.hh"
#include "debug/HWPrefetch.hh"
#include "mem/cache/prefetch/associative_set_impl.hh"
#include "mem/cache/replacement_policies/base.hh"

#include "params/StreamPrefetcher.hh"


namespace gem5
{

namespace prefetch
{


Stream::Stream(const StreamPrefetcherParams &p)
: Queued(p),
  tableSize(p.tableSize),
  useMasterId(p.use_master_id),
  degree(p.degree),
  distance(p.distance) {
    for(int i=0; i<MaxContexts; i++) {
        StreamTable[i] = new StreamTableEntry*[tableSize];
        for(int j=0; j<tableSize; j++) {
            StreamTable[i][j] = new StreamTableEntry[tableSize];
            StreamTable[i][j]->LRU_index = j;
            resetEntry(StreamTable[i][j]);
        }
    }
}

Stream::~Stream() {
     for (int i = 0; i < MaxContexts; i++) {
            for (int j = 0; j < tableSize; j++) {
                delete[] StreamTable[i][j];
            }
        }
}


// Training and Prefetching of streams
void
Stream::calculatePrefetch(const PrefetchInfo &pfi,
                                    std::vector<AddrPriority> &addresses) {
    uint32_t core_id = 0;
    Addr blk_addr = pfi.getAddr() & ~(Addr)(blkSize-1); // cache block aligned address.
    // assert(core_id < MaxContexts);
    StreamTableEntry** table;
    table = StreamTable[core_id];                          // Per core stream training.
    uint32_t i;
    // Check if there is a stream entry with the same address as blk_addr
    for (i = 0; i < tableSize; i++) {
        switch (table[i]->status) {
        case MONITOR:
            if(table[i]->trainedDirection == ASCENDING) {
                // Ascending order
                if((table[i]->startAddr < blk_addr ) && ( table[i]->endAddr > blk_addr)) {
                    // Hit to a stream, which is monitored. Issue prefetch requests based on the degree and the direction
                    for (uint8_t d = 1; d <= degree; d++) {
                        Addr pf_addr = table[i]->endAddr + blkSize * d;
                        addresses.push_back(AddrPriority(pf_addr,0));
                        DPRINTF(HWPrefetch, "Queuing prefetch to %#x.\n", pf_addr);
                    }
                    if((table[i]->endAddr + blkSize * degree) - table[i]->startAddr <= distance) {
                        table[i]->endAddr   = table[i]->endAddr + blkSize * degree;
                    } else {
                        table[i]->startAddr = table[i]->startAddr + blkSize * degree;
                        table[i]->endAddr   = table[i]->endAddr   + blkSize * degree;
                    }
                    break;
                }
            } else if(table[i]->trainedDirection == DESCENDING) {
                // Descending order
                if((table[i]->startAddr > blk_addr ) && (table[i]->endAddr < blk_addr)) {
                    for (uint8_t d = 1; d <= degree; d++) {
                        Addr pf_addr = table[i]->endAddr - blkSize * d;
                        addresses.push_back(AddrPriority(pf_addr,0));
                        DPRINTF(HWPrefetch, "Queuing prefetch to %#x.\n", pf_addr);
                    }
                    if(table[i]->startAddr - (table[i]->endAddr - blkSize * degree) <= distance){
                        table[i]->endAddr   = table[i]->endAddr - blkSize * degree;
                    } else {
                        table[i]->startAddr = table[i]->startAddr - blkSize * degree;
                        table[i]->endAddr   = table[i]->endAddr   - blkSize * degree;
                    }
                    break;
                }
            } else{
                assert(0);
            }
            break;
        case TRAINING:
            if ((abs(table[i]->allocAddr - blk_addr) <= (distance/2) * blkSize) ){
                // Check whether the address is in +/- of distance
                if(table[i]->trendDirection[0] == INVALID){
                    table[i]->trendDirection[0] = (blk_addr - table[i]->allocAddr > 0) ? ASCENDING : DESCENDING;
                } else {
                    assert(table[i]->trendDirection[1] == INVALID);
                    table[i]->trendDirection[1] = (blk_addr - table[i]->allocAddr > 0) ? ASCENDING : DESCENDING;
                    if(table[i]->trendDirection[0] == table[i]->trendDirection[1]) {
                        table[i]->trainedDirection = table[i]->trendDirection[0];
                        table[i]->startAddr = table[i]->allocAddr;
                        if(table[i]->trainedDirection != INVALID){
                            // Based on the trainedDirection (+1:Ascending, -1:Descending) update the end address of a stream
                            table[i]->endAddr = blk_addr + (table[i]->trainedDirection) * blkSize * degree;
                        }
                        // Entry is ready for issuing prefetch requests
                        table[i]->status = MONITOR;
                    } else {
                        resetEntry(table[i]);
                    }
                }
                break;
            }
            break;
        default:
            break;
        }  // End of Switch
    }  // End of for loop
    uint32_t HIT_index=i;
    int INVALID_index = tableSize;
    for (int i=0; i<tableSize; i++) {
        //find empty entry
        if(table[i]->status==INV) {
            INVALID_index = i;
            break;
        }
    }
    int TEMP_index = -1;
    int LRU_index = -1000000;
    for (int i=0; i<tableSize; i++) {
        //find empty entry
        if(table[i]->LRU_index > TEMP_index) {
            TEMP_index = table[i]->LRU_index;
            LRU_index  = i;
        }
    }
    assert(TEMP_index == tableSize - 1);
    int entry_id;
    if(HIT_index!=tableSize) {  //hit
        entry_id = HIT_index;
    } else if (INVALID_index!=tableSize) {
        //Existence of invalid streams
        assert(table[INVALID_index]->status == INV);
        table[INVALID_index]->status = TRAINING;
        table[INVALID_index]->allocAddr = blk_addr;
        entry_id = INVALID_index;
    } else {
        //Replace the LRU stream-entry
        assert(table[LRU_index]->status!=INV);
        resetEntry(table[LRU_index]);
        table[LRU_index]->status = TRAINING;
        table[LRU_index]->allocAddr = blk_addr;
        entry_id = LRU_index;
    }
    // Shifting the table entries after the eviction of lru-id
    for (int i=0; i<tableSize; i++) {
        if(table[i]->LRU_index < table[entry_id]->LRU_index){
            table[i]->LRU_index = table[i]->LRU_index + 1;
        }
    }
    table[entry_id]->LRU_index = 0;

}

void
Stream::resetEntry(StreamTableEntry *this_entry)
{

    this_entry->status                = INV;
    this_entry->trendDirection[0]     = INVALID;
    this_entry->trendDirection[1]     = INVALID;
    this_entry->allocAddr             = 0;
    this_entry->startAddr             = 0;
    this_entry->endAddr               = 0;
    this_entry->trainedDirection      = INVALID;

}

} // namespace prefetch

// prefetch::Stream *
// StreamPrefetcherParams::create() const
// {
//     return new prefetch::Stream(*this);
// }

} // namespace gem5

文件路径：./src/mem/cache/prefetch/stream.hh

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
#ifndef __MEM_CACHE_PREFETCH_STREAM_HH__
#define __MEM_CACHE_PREFETCH_STREAM_HH__

#include "mem/cache/prefetch/queued.hh"
#include "params/StreamPrefetcher.hh"
// Direction of stream for each stream entry in the stream table

#include "base/types.hh"

namespace gem5
{

namespace prefetch
{

enum StreamDirection{
        ASCENDING = 1,                      // For example - A, A+1, A+2
        DESCENDING = -1,                    // For example - A, A-1, A-2
        INVALID = 0
};
// Status of a stream entry in the stream table.
enum StreamStatus{
            INV       = 0,
            TRAINING  = 1,                  // Stream training is not over yet. Once trained will move to MONITOR status
            MONITOR   = 2                   // Monitor and Request: Stream entry ready for issuing prefetch requests
};


class Stream : public Queued {
  protected:
    static const uint32_t MaxContexts = 64; // Creates per-core stream tables for upto 64 processor cores
    uint32_t tableSize;                     // Number of entries in a stream table
    const bool useMasterId;                 // Use the master-id to train the streams
    uint32_t degree;                        // Determines the number of prefetch reuquests to be issued at a time
    uint32_t distance;                      // Determines the prefetch distance

   /* StreamTableEntry
     Stores the basic attributes of a stream table entry.
   */
  class StreamTableEntry {

      public:
        int  LRU_index;
        Addr allocAddr;                     // Address that initiated the stream training
        Addr startAddr;                     // First address of a stream
        Addr endAddr;                       // Last address of a stream
        StreamDirection trainedDirection;   // Direction of trained stream (Ascending or Descending)
        StreamStatus    status;             // Status of the stream entry
        StreamDirection trendDirection[2];  // Stores the last two stream directions of an entry

  };
  void resetEntry (StreamTableEntry *this_entry);

  /* Creating a StreamTable for each core with
     Tablesize as the number of stream entries
  */
  StreamTableEntry **StreamTable[MaxContexts];

  public:
  Stream(const StreamPrefetcherParams &p);
  ~Stream();
  /* Function called by cache controller to initiate
     the stream training process
  */
  // void calculatePrefetch(const PacketPtr &pkt, std::vector<AddrPriority> &addresses);
  void calculatePrefetch(const PrefetchInfo &pfi, std::vector<AddrPriority> &addresses);
};

} // namespace prefetch
} // namespace gem5

#endif // __MEM_CACHE_PREFETCH_STREAM_HH__

二、修改Prefetcher.py

文件路径：./src/mem/cache/prefetch/Prefetcher.py

新增代码块

1
2
3
4
5
6
7
8
9
10
class StreamPrefetcher(QueuedPrefetcher):
    type = 'StreamPrefetcher'
    cxx_class = 'gem5::prefetch::Stream'
    cxx_header = "mem/cache/prefetch/stream.hh"
    table_sets = Param.Int(16, "Number of sets in PC lookup table")
    table_assoc = Param.Int(4, "Associativity of PC lookup table")
    tableSize = Param.Int(8, "Number of sets in PC lookup table")
    distance = Param.Int(5, "Associativity of PC lookup table")
    use_master_id = Param.Bool(True, "Use master id based history")
    degree = Param.Int(4, "Number of prefetches to generate")

三、修改Sconscript

文件路径：./src/mem/cache/prefetch/Sconscript

1
2
3
4
5
6
7
8
SimObject('Prefetcher.py', sim_objects=[
    'BasePrefetcher', 'MultiPrefetcher', 'QueuedPrefetcher',
    'StridePrefetcherHashedSetAssociative', 'StridePrefetcher',
    'TaggedPrefetcher', 'IndirectMemoryPrefetcher', 'SignaturePathPrefetcher',
    'SignaturePathPrefetcherV2', 'AccessMapPatternMatching', 'AMPMPrefetcher',
    'DeltaCorrelatingPredictionTables', 'DCPTPrefetcher',
    'IrregularStreamBufferPrefetcher', 'SlimAMPMPrefetcher',
    'BOPPrefetcher', 'SBOOEPrefetcher', 'STeMSPrefetcher', 'PIFPrefetcher'])

修改为
1
2
3
4
5
6
7
8
9
10
SimObject('Prefetcher.py', sim_objects=[
    'BasePrefetcher', 'MultiPrefetcher', 'QueuedPrefetcher',
    'StridePrefetcherHashedSetAssociative', 'StridePrefetcher', 'StreamPrefetcher',
    'TaggedPrefetcher', 'IndirectMemoryPrefetcher', 'SignaturePathPrefetcher',
    'SignaturePathPrefetcherV2', 'AccessMapPatternMatching', 'AMPMPrefetcher',
    'DeltaCorrelatingPredictionTables', 'DCPTPrefetcher',
    'IrregularStreamBufferPrefetcher', 'SlimAMPMPrefetcher',
    'BOPPrefetcher', 'SBOOEPrefetcher', 'STeMSPrefetcher', 'PIFPrefetcher'])

Source('stream.cc')

重新编译之后就能使用StreamPrefetcher参数配置预取器了。

1
2
3
4
5
6
7
8
9
10
11
12
13
14
"prefetcher": {
                "type": "StreamPrefetcher",
                "cxx_class": "gem5::prefetch::Stream",
                "name": "prefetcher",
                "path": "system.l2.prefetcher",
                "block_size": 64,
                "cache_snoop": false,
                "clk_domain": "system.cpu_clk_domain",
                "degree": 1,
                "distance": 5,
                "eventq_index": 0,
                "latency": 1,
                ...
}
